Product Description
Quilting machine mainly use for quilting mattresses, bedspreads, quilts . The working prrinciple is similar to the sewing machine.(The sewing machine moves: the textile moves, the machine is stationary. The quilting machine moves: the machine moves the textile to be stationary).
Single needle quilting machine can be widely used for quilting of various quilts, sleeping bags, bedspreads and curtains.
1, Single needle quilting machine computer Chinese and English layout, easy to operate.
2, quilting size, needle speed, stitch length, pattern, etc. can be adjusted at will.
3, using broken line detection, automatic memory return, automatic repair and other functions.
4, computer screen work status tracking color display, automatic cumulative output, etc.
5, Single needle quilting machine can be customized according to user needs of various sizes.
6. in machine have 300 patterns .also supply the pattern design as you require.
| Model | KVQ-22*24 | KVQ-24*26 | KVQ-26*28 | KVQ-28*30 |
| Max.quilt size | 2.2*2.4m | 2.4*2.6m | 2.6*2.8m | 2.8*3.0m |
| Needle drop size | 2.0*2.2m | 2.2-2.4m | 2.4*2.6m | 2.6*2.8m |
| Power | 220V 50HZ/60HZ 1.5kw | |||
| Quilting thickness | 1200g/m2 | |||
| Sewing speed | 1300-2200r/min | |||
| Needle | DP5 18~22# | |||
| Dimension | 3*3*1.4m | 3.2*3.2*1.4m | 3.4*3.4*1.4m | 3.6*3.6*1.4m |
| Weight | 720kg | 750kg | 800kg | 850kg |
2. stepper motors
3. about 300 patterns
4. LCD touch screen
2. servo model with automatic cutting thread single head quilting machine quilting
1: using cam circular knife to cut, fast thread trimming speed.
2: Direct drive nose and direct drive bottom seat.
3: The maximum speed is 2400, so that it does not decelerate when cornering.
4: Using 8-inch QC800 full touch screen, Chinese and English can be switched at any time.
3. zhengbu system with cutting thread function Single needle quilting machine
2.Moving Style:Head Moved, frame moved
3.automatic cutting thread
4.automatic back to strat point
5.Driect drive sewing head
6.zhengbu computer
7. zhengbu system Interface
2:10 inch LCD touch screen.
3: Support 7 languages. .Chinese, English, Spanish, Russian, French, Turkish, German
4: Pneumatic lift head. fully automatic computerized quilting machine single needle duvet quilt making sewing machine
5: Full servo motors (4 pcs).
6: Adopt 6 high-precision linear slider guides.
7: High-speed direct-drive head.
8: High-speed direct-drive cam automatic trimming bottom seat.
9: Automatic timing refueling.
10: The rotary shuttle automatically removes dust regularly.
11: Automatically press the quilt frame when quilting.
| before sales | 24 hours online service .in time reply Any in Any inquiries will be replied within 12 hours offer professional machine details and information technology knowledge share . |
| on sale | Protect the client payment security . reasonable price and ensure quality . send machine pictures , videos as client need and let client know machine more better |
| | Fast delivery and test and adjust machine working well before delivery Supply manual book and technical support in order to use well offer install pictures step by step or videos and dispatch the engineer Guarantee time is one year . during one year . offer the spare parts for free |
Q:Who are we?
A: We are zhengzhou kovi machinery, a professional textile machinery manufacturer, more than 98% machine production processes made in our workshop, we can offer complete customized services according to your requirements.
Q: Why you should choose us?
A: We have our own research and development department, several professional engineers, strong customized ability according to customers requests.
Q: What about your warranty?
A: Our warranty is 1 year, and offer full life technology support.
Q: How long we will get the machine?
A: Generally delivery time is 5-7 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to detailed request.
Q: Are we still need to install the machine after we got?
A: All of machine already testing ready, and all parameter is settled ok before we deliver to you, also we can send you video and manual to teach you how to use the machine.
Q: How can you guarantee we receive a good quality?
A: We have serious inspection process department to control the quality. When the machine was finished, we should send you the inspection video and pictures.
Q: What business terms and payment way we can do?
A: Accepted Delivery Terms: FOB, CFR, CIF, EXW, FCA, DDP, DDU, Express Delivery;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, Western Union, Cash.
