Product Description
Quilting machine mainly use for quilting mattresses, bedspreads, quilts . The working prrinciple is similar to the sewing machine.(The sewing machine moves: the textile moves, the machine is stationary. The quilting machine moves: the machine moves the textile to be stationary).
It can be widely used for quilting of various quilts, sleeping bags, bedspreads and curtains.
1, computer Chinese and English layout, easy to operate.
2, quilting size, needle speed, stitch length, pattern, etc. can be adjusted at will.
3, using broken line detection, automatic memory return, automatic repair and other functions.
4, computer screen work status tracking color display, automatic cumulative output, etc.
5, can be customized according to user needs of various sizes.
6. in machine have 300 patterns .also supply the pattern design as you require.
The quilting machine is a system that moves in an XY-Z pattern. The XY axis controls the movement of the machine head, and the Z axis controls the quilting of the machine head.
1. Z-axis movement - the up and down movement of the quilting needle.
2. X-axis movement - the head of the quilting machine moves left and right.
3. Y-axis movement - the head of the quilting machine moves forward and backward.
4. The movement of the X and Y axes - depends on a template under the machine, and quilting is performed according to the pattern trend on it.
| computer single needle sewing machine | ||||
| Model | MKQ-22*24 | MKQ-24*26 | MKQ-26*28 | MKQ-28*30 |
| Max.quilt size | 2.2*2.4m | 2.4*2.6m | 2.6*2.8m | 2.8*3.0m |
| Needle drop size | 2.0*2.2m | 2.2-2.4m | 2.4*2.6m | 2.6*2.8m |
| Power | 220V 50HZ/60HZ 1.5kw | |||
| Quilting thickness | 1200g/m2 | |||
| Sewing speed | 1300-2200r/min | |||
| Needle | DP5 18~22# | |||
| Dimension | 3*3*1.4m | 3.2*3.2*1.4m | 3.4*3.4*1.4m | 3.6*3.6*1.4m |
| Weight | 720kg | 750kg | 800kg | 850kg |
Quilting machine of Zhengbu systerm without automatic cutting thread
Q:Who are we?
A: We are zhengzhou kovi machinery, a professional textile machinery manufacturer, more than 98% machine production processes made in our workshop, we can offer complete customized services according to your requirements.
Q: Why you should choose us?
A: We have our own research and development department, several professional engineers, strong customized ability according to customers requests.
Q: What about your warranty?
A: Our warranty is 1 year, and offer full life technology support.
Q: How long we will get the machine?
A: Generally delivery time is 5-7 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to detailed request.
Q: Are we still need to install the machine after we got?
A: All of machine already testing ready, and all parameter is settled ok before we deliver to you, also we can send you video and manual to teach you how to use the machine.
Q: How can you guarantee we receive a good quality?
A: We have serious inspection process department to control the quality. When the machine was finished, we should send you the inspection video and pictures.
Q: What business terms and payment way we can do?
A: Accepted Delivery Terms: FOB, CFR, CIF, EXW, FCA, DDP, DDU, Express Delivery;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, Western Union, Cash.
