Basic Info.
Model NO.
HL-5200
Needle Number
Single Needle
Stitch Type
Lock Type
Stitch Length
0-5mm
Presser Foot Lifting
4-9mm
Max Sewing Speed
5000rpm
Power
400W/370W/110V/220V
Quality Certificate
ISO, Ce
Automatic Grade
Automatic
Transport Package
Standard Export Carton
Specification
635*235*540mm
Trademark
HIGHLY or your OEM brand
Origin
Zhejiang, China
HS Code
8452290000
Production Capacity
1000PCS/Month
Product Description
Model | HL-5200 / HL-5200D / HL-5200D-QB | ||||
Stitch Formation | Lockstitch | ||||
Mechanical Type | Flat Bed | ||||
Max Sewing Thickness | 5.5-15mm | ||||
Max. sewing speed | 5000rpm | ||||
Stitch Length | 0-5mm | ||||
Presser Foot Lifting | 4-9mm | ||||
Type of Needle | DBX1 #8-#18 | ||||
Packing Size | 680*245*523mm | ||||
Weight | 40/37kgs |
HL-5200D High Speed Direct Drive Single Needle Lockstitch Sewing Machine with Side Knife
1. Computer high speed direct drive lockstitch sewing machine with integrative computer controller, it can be used when it's plugged in electricity, leaving out the problem of all kinds of plugs chaos and installing.
2. It has the sewing functions of auto-trimmer, automatic needle position, automatic sitch storage, auto presser foot lifting, auto back forward sewing, auoto thread winding, soft start, filling needle and so on.
3. It adopts good feeding machanism, which greatly improves the production efficiency. It's internally installed bobbin winder which is elegant and easy to handle.
4. It can prevent oil leak from head to servo control system so that reducing stoppage and extending service life. Low noise, no radiation and environmental friendly.
5. The most saving of power; the most effect of lubricate system. Adopt inside directly driver servo motor, make the consumption of electricity reduced by 70%.
